Overview
A figure set rather than a written procedure: one Word document of eleven activity-classified model design figures, issued as a companion to the AGS Design and Construction Guidelines (AGS-DGL-01). It opens with the method, Figure 0, the logical distribution of zones in the I-shape.
That one-direction logic is then applied to each family of food facility in turn, from processing plants and slaughterhouses to kitchens, bakeries and markets. Every figure is a reference layout to adapt to a real site, not a fixed plan to be traced.
What it covers
- Figure 0: the logical distribution of zones by the I-shape method
- Fruit and vegetable processing, edible oil refining and fish canning plant flows
- Restaurant, fast food, hotel and central kitchen activity flows
- Livestock, sheep and poultry slaughterhouse flows, and sausage production
- Bakery flow and central market activity layout
Who it's for
Architects, facility planners, franchise development teams and plan-review officials needing a credible model layout for a specific food-industry activity. It earns its place at the drawing stage, when a plan is prepared for submission or reviewed against flow requirements, and settles the zoning argument before the walls go up.
Everything you get
Every toolkit gives you a full set of working documents for your standard, ready to edit and use.
Native Microsoft files. Add your logo and adapt every document to how you work.
Your full toolkit arrives as a ZIP the moment payment clears.
One purchase covers everyone in your organisation. No per-seat fees.
Built by people who run real audits, so the content matches what assessors check.
One payment, perpetual licence for your organisation. No subscriptions, no renewals.
Full refund if your files are faulty, incomplete or not as described and we can't put it right
